PVC windows and doors

PVC window profile systems

Framex 71 is a universal 6-chamber PVC system with an installation depth of 71 mm, designed for various types of windows and doors. It offers high energy efficiency and sound insulation, making it ideal for both residential and commercial applications.

Key Characteristics:
System Type: PVC Window and Door System
Chambers: 6
Installation Depth: 71 mm
Uf (Profile Heat Transfer Coefficient): 1.2 W/m²K
Max. Glazing Thickness: Up to 42 mm
Sealing Contours: 2
Burglar Resistance: RC2 (optional)
Applications: Windows, balcony doors, folding-sliding systems, residential, commercial

Framex 80 is a premium 7-chamber PVC system with an 80 mm installation depth, engineered for superior comfort and excellent energy efficiency. It meets Passive House standards, providing outstanding protection against noise, cold, and moisture.

Key Characteristics:
System Type: PVC Window and Door System
Chambers: 7
Installation Depth: 80 mm
Uw (Window Heat Transfer Coefficient): Down to 0.76 W/m²K (with appropriate glazing)
Max. Glazing Thickness: Up to 50 mm
Sealing Contours: 3
Sound Insulation: Up to Rw 45 dB
Burglar Resistance: RC2 (optional)
Special Features: Glass bonding technology, elegant design
Applications: Modern residential, commercial, Passive House projects

Framex Inova ISS 147 is a warm parallel-sliding PVC system designed for contemporary spaces, featuring a 147 mm frame depth. It ensures high levels of thermal, water, and sound insulation, perfect for connecting indoor and outdoor areas.

Key Characteristics:
System Type: Parallel-Sliding PVC System
Frame Installation Depth: 147 mm
Max. Infill/Glazing Thickness: Up to 50 mm
Sealing Contours: Double (TPE)
Air Permeability Class: 4
Water Tightness Class: 8A
Burglar Resistance: RC2
Max. Sash Weight: Up to 200 kg
Special Features: Micro-ventilation function
Applications: Large panoramic doors, terraces, gardens, modern architecture

Framex HS 170 is a robust lift-and-slide PVC system, ideal for large openings requiring extensive glazing. It provides excellent panoramic views alongside high thermal and sound insulation, designed for durability and stability.

Key Characteristics:
System Type: Lift-and-Slide PVC System
Installation Depth: 170 mm
Uf (Profile Heat Transfer Coefficient): 1.5 W/m²K
Max. Sash Weight: Up to 400 kg
Max. Glazing Thickness: Up to 40 mm
Special Features: Floor-to-ceiling glazing, high wind and thermal load resistance, durable reinforced profile
Applications: Large entrance groups, loggia exits, hotels, cottages, panoramic views

The profile can be standard white or colored. PVC can be laminated on both sides – in the desired color of lamination at the customer’s request.

The profile systems are certified, meet international requirements and have successfully passed tests at the Institute of Window Technologies IFT Rosenheim (Germany).
